3 601 K68 500
Protective Cover
-
Spare part number: 1 619 PA5 004
Position: 12
Availability: 1
Price group: -
-
Hex Socket Head Cap Screw
-
Spare part number: 1 619 PA5 043
Position: 65
Availability: 1
Price group: -
-
Hex head tapping screw
-
Spare part number: 1 619 PA5 044
Position: 67
Availability: 1
Price group: -
-
Screw
-
Spare part number: 1 619 PA5 048
Position: 8
Availability: 1
Price group: -
-
Piston
-
Spare part number: 1 619 PA5 049
Position: 16
Availability: 1
Price group: -
-
Focusing device 16MM
-
Spare part number: 1 619 PA5 229
Position: 23
Availability: 1
Price group: -
-
Telescope GOL 32 D
-
Spare part number: 1 619 PA5 231
Position: 40
Availability: 1
Price group: -
-
Mounting Kit
-
Spare part number: 1 619 PA5 233
Position: 73
Availability: 1
Price group: -
-
Spacer
-
Spare part number: 1 619 PB5 537
Position: 78
Availability: 1
Price group: -
-
sleeve
-
Spare part number: 1 619 PB5 538
Position: 66
Availability: 1
Price group: -
-
Screw
-
Spare part number: 2 610 A02 324
Position: 1
Availability: 9
Price group: -
-
Screw
-
Spare part number: 2 610 A02 324
Position: 1
Availability: 9
Price group: -
-
Screw
-
Spare part number: 2 610 A02 324
Position: 1
Availability: 9
Price group: -
-
Indicator
-
Spare part number: 2 610 A03 339
Position: 39
Availability: 1
Price group: -
-
Compensator
-
Spare part number: 2 610 A03 364
Position: 3
Availability: 1
Price group: -
-
Lens
-
Spare part number: 2 610 A03 366
Position: 26
Availability: 1
Price group: -
-
O-Ring
-
Spare part number: 2 610 A03 367
Position: 35
Availability: 1
Price group: -
-
Screw
-
Spare part number: 2 610 A03 368
Position: 38
Availability: 1
Price group: -
-
Set screw
-
Spare part number: 2 610 A03 370
Position: 60
Availability: 1
Price group: -
-
Cross hair insert
-
Spare part number: 2 610 A03 372
Position: 77
Availability: 1
Price group: -
-
Pusher
-
Spare part number: 2 610 A03 377
Position: 28
Availability: 1
Price group: -
-
Reader
-
Spare part number: 2 610 A03 379
Position: 34
Availability: 1
Price group: -
-
Screw
-
Spare part number: 2 610 A03 380
Position: 31
Availability: 2
Price group: -
-
Screw
-
Spare part number: 2 610 A03 382
Position: 59
Availability: 1
Price group: -
-
viewfinder tube
-
Spare part number: 2 610 A03 383
Position: 64
Availability: 1
Price group: -
-
Spacer
-
Spare part number: 2 610 A03 392
Position: 27
Availability: 1
Price group: -
-
Cap
-
Spare part number: 2 610 A03 394
Position: 24
Availability: 1
Price group: -
-
Cap
-
Spare part number: 2 610 A03 404
Position: 23/14
Availability: 1
Price group: -
-
Contact strap
-
Spare part number: 2 610 A05 649
Position: 29
Availability: 1
Price group: -
-
Toothed rack
-
Spare part number: 2 610 A05 652
Position: 30
Availability: 1
Price group: -
-
Lens
-
Spare part number: 2 610 A05 653
Position: 32
Availability: 1
Price group: -
-
Contact strap
-
Spare part number: 2 610 A05 662
Position: 5
Availability: 2
Price group: -
-
Cap
-
Spare part number: 2 610 A05 677
Position: 58/1
Availability: 1
Price group: -
-
Cap
-
Spare part number: 2 610 A05 677
Position: 58/1
Availability: 1
Price group: -
-
Contact strap
-
Spare part number: 2 610 A05 697
Position: 63
Availability: 1
Price group: -
-
Screw
-
Spare part number: 2 610 A05 702
Position: 58
Availability: 1
Price group: -
-
Screw
-
Spare part number: 2 610 A05 702
Position: 58
Availability: 1
Price group: -
-
Bubble Level
-
Spare part number: 2 610 A05 718
Position: 62
Availability: 1
Price group: -
-
Set screw
-
Spare part number: 2 610 A05 724
Position: 11
Availability: 3
Price group: -
-
Screw
-
Spare part number: 2 610 A05 726
Position: 10
Availability: 4
Price group: -
-
eyepiece
-
Spare part number: 2 610 A05 730
Position: 14
Availability: 1
Price group: -
-
mat seal
-
Spare part number: 2 610 A05 731
Position: 15
Availability: 1
Price group: -
-
Pivot Pin
-
Spare part number: 2 610 A05 748
Position: 2
Availability: 1
Price group: -
-
Transport Lock
-
Spare part number: 2 610 A05 751
Position: 37
Availability: 1
Price group: -
-
Screw
-
Spare part number: 2 610 A05 758
Position: 61
Availability: 1
Price group: -
-
Cover
-
Spare part number: 2 610 A11 683
Position: 13
Availability: 1
Price group: -
-
Cover Ring
-
Spare part number: 2 610 A11 684
Position: 25
Availability: 1
Price group: -
-
mat seal
-
Spare part number: 2 610 A11 904
Position: 36
Availability: 1
Price group: -
-
Base Plate
-
Spare part number: 1 619 PA5 054
Position: 56
Availability: 1
Price group: -
-
Screw
-
Spare part number: 1 619 PA5 234
Position: 74
Availability: 3
Price group: -
-
Washer
-
Spare part number: 1 619 PA5 235
Position: 75
Availability: 3
Price group: -
-
Screw
-
Spare part number: 1 619 PA5 236
Position: 76
Availability: 1
Price group: -
-
Indicator
-
Spare part number: 2 610 A03 339
Position: 39
Availability: 1
Price group: -
-
Adjusting Screw
-
Spare part number: 2 610 A05 628
Position: 18
Availability: 3
Price group: -
-
Tension Cone
-
Spare part number: 2 610 A05 629
Position: 19
Availability: 3
Price group: -
-
Washer
-
Spare part number: 2 610 A05 630
Position: 20
Availability: 3
Price group: -
-
Nut
-
Spare part number: 2 610 A05 631
Position: 21
Availability: 3
Price group: -
-
Washer
-
Spare part number: 2 610 A05 665
Position: 43
Availability: 1
Price group: -
-
Retaining ring
-
Spare part number: 2 610 A05 666
Position: 44
Availability: 1
Price group: -
-
Gear
-
Spare part number: 2 610 A05 667
Position: 45
Availability: 1
Price group: -
-
Contact strap
-
Spare part number: 2 610 A05 669
Position: 46
Availability: 1
Price group: -
-
Spring retaining ring
-
Spare part number: 2 610 A05 671
Position: 47
Availability: 1
Price group: -
-
Graduated Disc
-
Spare part number: 2 610 A05 673
Position: 49
Availability: 1
Price group: -
-
Washer
-
Spare part number: 2 610 A05 675
Position: 50
Availability: 1
Price group: -
-
Base Plate
-
Spare part number: 2 610 A05 691
Position: 52
Availability: 1
Price group: -
-
Ball seat
-
Spare part number: 2 610 A05 693
Position: 53
Availability: 3
Price group: -
-
Screw
-
Spare part number: 2 610 A05 694
Position: 51
Availability: 3
Price group: -
-
Screw
-
Spare part number: 2 610 A05 734
Position: 57
Availability: 3
Price group: -
-
Retaining ring
-
Spare part number: 2 610 A05 744
Position: 48
Availability: 1
Price group: -
-
Cover Plate
-
Spare part number: 2 610 A11 687
Position: 55
Availability: 1
Price group: -
-
1
2
Spare parts in cart
65 Parts found
Sort by
Description
Pos. 1 | Screw
2 610 A02 324
-
Pos. 2 | Pivot Pin
2 610 A05 748
-
Pos. 3 | Compensator
2 610 A03 364
-
Pos. 5 | Contact strap
2 610 A05 662
-
Pos. 8 | Screw
1 619 PA5 048
-
Pos. 10 | Screw
2 610 A05 726
-
Pos. 11 | Set screw
2 610 A05 724
-
Pos. 12 | Protective Cover
1 619 PA5 004
-
Pos. 13 | Cover
2 610 A11 683
-
Pos. 14 | eyepiece
2 610 A05 730
-
Pos. 15 | mat seal
2 610 A05 731
-
Pos. 16 | Piston
1 619 PA5 049
-
Pos. 18 | Adjusting Screw
2 610 A05 628
-
Pos. 19 | Tension Cone
2 610 A05 629
-
Pos. 20 | Washer
2 610 A05 630
-
Pos. 21 | Nut
2 610 A05 631
-
Pos. 23 | Focusing device 16MM
1 619 PA5 229
-
Pos. 23/14 | Cap
2 610 A03 404
-
Pos. 24 | Cap
2 610 A03 394
-
Pos. 25 | Cover Ring
2 610 A11 684
-
Pos. 26 | Lens
2 610 A03 366
-
Pos. 27 | Spacer
2 610 A03 392
-
Pos. 28 | Pusher
2 610 A03 377
-
Pos. 29 | Contact strap
2 610 A05 649
-
Pos. 30 | Toothed rack
2 610 A05 652
-
Pos. 31 | Screw
2 610 A03 380
-
Pos. 32 | Lens
2 610 A05 653
-
Pos. 34 | Reader
2 610 A03 379
-
Pos. 35 | O-Ring
2 610 A03 367
-
Pos. 36 | mat seal
2 610 A11 904
-
Pos. 37 | Transport Lock
2 610 A05 751
-
Pos. 38 | Screw
2 610 A03 368
-
Pos. 39 | Indicator
2 610 A03 339
-
Pos. 40 | Telescope GOL 32 D
1 619 PA5 231
-
Pos. 43 | Washer
2 610 A05 665
-
Pos. 44 | Retaining ring
2 610 A05 666
-
Pos. 45 | Gear
2 610 A05 667
-
Pos. 46 | Contact strap
2 610 A05 669
-
Pos. 47 | Spring retaining ring
2 610 A05 671
-
Pos. 48 | Retaining ring
2 610 A05 744
-
Pos. 49 | Graduated Disc
2 610 A05 673
-
Pos. 50 | Washer
2 610 A05 675
-
Pos. 51 | Screw
2 610 A05 694
-
Pos. 52 | Base Plate
2 610 A05 691
-
Pos. 53 | Ball seat
2 610 A05 693
-
Pos. 55 | Cover Plate
2 610 A11 687
-
Pos. 56 | Base Plate
1 619 PA5 054
-
Pos. 57 | Screw
2 610 A05 734
-
Pos. 58 | Screw
2 610 A05 702
-
Pos. 58/1 | Cap
2 610 A05 677
-
Pos. 59 | Screw
2 610 A03 382
-
Pos. 60 | Set screw
2 610 A03 370
-
Pos. 61 | Screw
2 610 A05 758
-
Pos. 62 | Bubble Level
2 610 A05 718
-
Pos. 63 | Contact strap
2 610 A05 697
-
Pos. 64 | viewfinder tube
2 610 A03 383
-
Pos. 65 | Hex Socket Head Cap Screw
1 619 PA5 043
-
Pos. 66 | sleeve
1 619 PB5 538
-
Pos. 67 | Hex head tapping screw
1 619 PA5 044
-
Pos. 73 | Mounting Kit
1 619 PA5 233
-
Pos. 74 | Screw
1 619 PA5 234
-
Pos. 75 | Washer
1 619 PA5 235
-
Pos. 76 | Screw
1 619 PA5 236
-
Pos. 77 | Cross hair insert
2 610 A03 372
-
Pos. 78 | Spacer
1 619 PB5 537
-
