3 601 JK3 180
Switchover Unit
-
Spare part number: 1 600 A01 2MM
Position: 32
Availability: 1
Price group: -
-
Changeover Lever
-
Spare part number: 1 600 A01 Z04
Position: 5
Availability: 1
Price group: -
-
Gear Box
-
Spare part number: 1 600 A01 ZT9
Position: 45
Availability: 1
Price group: -
-
Clip
-
Spare part number: 1 600 A02 7W3
Position: 652
Availability: 1
Price group: -
-
Keyless Chuck
-
Spare part number: 1 600 A02 7W8
Position: 25
Availability: 1
Price group: -
-
Nameplate
-
Spare part number: 1 601 11A D48
Position: 808
Availability: 1
Price group: -
-
Sticker
-
Spare part number: 1 601 11C 49H
Position: 42
Availability: 1
Price group: -
-
Manufacturer's nameplate
-
Spare part number: 1 601 11C 4DD
Position: 9
Availability: 1
Price group: -
-
Housing
-
Spare part number: 1 605 806 62H
Position: 1
Availability: 1
Price group: -
-
Housing
-
Spare part number: 1 605 806 62H
Position: 1
Availability: 1
Price group: -
-
Rotor
-
Spare part number: 1 607 000 EC2
Position: 802
Availability: 1
Price group: -
-
-
Please click for futher details
-
Please click for futher details
Compression Spring
-
Spare part number: 1 609 280 477
Position: 46
Availability: 1
Price group: -
-
Stator
-
Spare part number: 1 619 P15 696
Position: 3
Availability: 1
Price group: -
-
Countersunk-Head Screw M6X23 LEFTHAND THREADS
-
Spare part number: 2 603 421 229
Position: 107
Availability: 1
Price group: 00
GH₵ 4.12*
Prices shown are recommended retail prices including VAT
Electronics Module
-
Spare part number: 2 607 202 513
Position: 6
Availability: 1
Price group: -
-
-
Please click for futher details
-
Please click for futher details
-
Please click for futher details
Torx Flat-Head Screw 3X16
-
Spare part number: 2 609 110 201
Position: 101
Availability: 10
Price group: -
-
1
Spare parts in cart
20 Parts found
Sort by
Description
Pos. 1 | Housing
1 605 806 62H
-
Pos. 3 | Stator
1 619 P15 696
-
Pos. 5 | Changeover Lever
1 600 A01 Z04
-
Pos. 6 | Electronics Module
2 607 202 513
-
Pos. 9 | Manufacturer's nameplate
1 601 11C 4DD
-
Pos. 25 | Keyless Chuck
1 600 A02 7W8
-
Pos. 32 | Switchover Unit
1 600 A01 2MM
-
Pos. 42 | Sticker
1 601 11C 49H
-
Pos. 45 | Gear Box
1 600 A01 ZT9
-
Pos. 46 | Compression Spring
1 609 280 477
-
Pos. 91 | Battery Pack GBA 18V 2.0AH
1 607 A35 0MN
-
Pos. 91 | Battery Pack
1 607 A35 0V8
-
Pos. 101 | Torx Flat-Head Screw 3X16
2 609 110 201
-
Pos. 107 | Countersunk-Head Screw M6X23 LEFTHAND THREADS
2 603 421 229
-
*Prices shown are recommended retail prices including VAT
Pos. 652 | Clip
1 600 A02 7W3
-
Pos. 653 | Fast Charger
2 607 226 281
-
Pos. 653 | Fast Charger UK GAL 18V-20 220-240V / 2A / 12-18V
2 607 226 283
-
Pos. 653 | Fast Charger LAM GAL18V-20
2 607 226 289
-
Pos. 802 | Rotor
1 607 000 EC2
-
Pos. 808 | Nameplate
1 601 11A D48
-
* Prices shown are recommended retail prices including VAT
