GWS 18V-15 SC - 3 601 JH6 102 | Product Detail Page | Power Tools

53.00 RM*

*Prices shown are net prices excluding VAT

Pos. 2

Pos. 2 | DC motor

1 607 022 661

DC motor

1 607 022 661

393.00 RM*

Availability 1

Price group: 46

393.00 RM*

*Prices shown are net prices excluding VAT

Pos. 3

Pos. 3 | Contact Plate

1 600 A02 4C4

Contact Plate

1 600 A02 4C4

28.00 RM*

Availability 1

Price group: 23

28.00 RM*

*Prices shown are net prices excluding VAT

Pos. 4

Pos. 4 | Switch Unit

1 600 A01 6JC

Switch Unit

1 600 A01 6JC

46.00 RM*

Availability 1

Price group: 28

46.00 RM*

*Prices shown are net prices excluding VAT

Pos. 7

Pos. 7 | Cover Ring

1 600 A01 6U4

Cover Ring

1 600 A01 6U4

6.00 RM*

Availability 1

Price group: 11

6.00 RM*

*Prices shown are net prices excluding VAT

Pos. 9

Pos. 9 | Manufacturer's nameplate

1 601 11C 2SD

Manufacturer's nameplate

1 601 11C 2SD

4.00 RM*

Availability 1

Price group: 13

4.00 RM*

*Prices shown are net prices excluding VAT

Pos. 18

Pos. 18 | Switch Handle

1 600 A01 6PW

Switch Handle

1 600 A01 6PW

2.00 RM*

Availability 1

Price group: 10

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 19

Pos. 19 | Compression Spring

1 604 612 03M

Compression Spring

1 604 612 03M

2.00 RM*

Availability 1

Price group: 10

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 20

Pos. 20 | Switch Slide

1 600 A01 6PX

Switch Slide

1 600 A01 6PX

2.00 RM*

Availability 1

Price group: 10

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 33

Pos. 33 | O-Ring 46,0X1,1 MM

1 600 210 035

O-Ring 46,0X1,1 MM

1 600 210 035

4.00 RM*

Availability 1

Price group: 11

4.00 RM*

*Prices shown are net prices excluding VAT

Pos. 35

Pos. 35 | Shim 0,1 MM THICK

1 600 136 013

Shim 0,1 MM THICK

1 600 136 013

2.00 RM*

Availability 1

Price group: 13

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 35

Pos. 35 | Shim 0,2 MM THICK

1 600 136 014

Shim 0,2 MM THICK

1 600 136 014

2.00 RM*

Availability 1

Price group: 13

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 35

Pos. 35 | Shim 0,3 MM THICK

1 600 136 015

Shim 0,3 MM THICK

1 600 136 015

2.00 RM*

Availability 1

Price group: 13

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 35

Pos. 35 | Shim 0,15 MM THICK

1 600 136 020

Shim 0,15 MM THICK

1 600 136 020

2.00 RM*

Availability 1

Price group: 13

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 45

Pos. 45 | Hex Nut M7, SW10

1 603 300 016

Hex Nut M7, SW10

1 603 300 016

2.00 RM*

Availability 1

Price group: 11

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 47

Pos. 47 | Compression Spring

1 609 280 477

Compression Spring

1 609 280 477

2.00 RM*

Availability 1

Price group: 11

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 49

Pos. 49 | Thread-forming tap. Screw M4X16

2 914 491 410

Thread-forming tap. Screw M4X16

2 914 491 410

2.00 RM*

Availability 4

Price group: 10

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 50

Pos. 50 | Thread-forming tap. Screw

1 603 435 071

Thread-forming tap. Screw

1 603 435 071

2.00 RM*

Availability 4

Price group: 10

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 53

Pos. 53 | Torx Oval-Head Screw

1 603 435 078

Torx Oval-Head Screw

1 603 435 078

2.00 RM*

Availability 3

Price group: 10

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 54

Pos. 54 | Torx Oval-Head Screw 4X30

1 603 414 026

Torx Oval-Head Screw 4X30

1 603 414 026

2.00 RM*

Availability 1

Price group: 10

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 55

Pos. 55 | Screw

1 603 430 03T

Screw

1 603 430 03T

2.00 RM*

Availability 5

Price group: 10

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 90

Pos. 90 | Electronic Module

1 607 233 5LN

Electronic Module

1 607 233 5LN

108.00 RM*

Availability 1

Price group: 36

108.00 RM*

*Prices shown are net prices excluding VAT

Pos. 92

Pos. 92 | Electronics Module

1 600 A01 3WF

Electronics Module

1 600 A01 3WF

115.00 RM*

Availability 1

Price group: 34

115.00 RM*

*Prices shown are net prices excluding VAT

Pos. 94

Pos. 94 | Cover

1 605 500 2FA

Cover

1 605 500 2FA

4.00 RM*

Availability 1

Price group: 11

4.00 RM*

*Prices shown are net prices excluding VAT

Pos. 95

Pos. 95 | Dust-Protection Cover

1 600 A01 9TY

Dust-Protection Cover

1 600 A01 9TY

3.00 RM*

Availability 1

Price group: 10

3.00 RM*

*Prices shown are net prices excluding VAT

Pos. 321/41

Pos. 321/41 | Plain bearing

1 600 200 029

Plain bearing

1 600 200 029

4.00 RM*

Availability 1

Price group: 14

4.00 RM*

*Prices shown are net prices excluding VAT

Pos. 321/104

Pos. 321/104 | O-Ring 4,5X1,0 MM BLUE

1 600 210 044

O-Ring 4,5X1,0 MM BLUE

1 600 210 044

2.00 RM*

Availability 1

Price group: 10

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 343

Pos. 343 | Catch Lever

1 607 000 742

Catch Lever

1 607 000 742

9.00 RM*

Availability 1

Price group: 20

9.00 RM*

*Prices shown are net prices excluding VAT

Pos. 343/44

Pos. 343/44 | Compression Spring

1 604 611 042

Compression Spring

1 604 611 042

2.00 RM*

Availability 1

Price group: 11

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 650/1

Pos. 650/1 | Auxiliary Handle

1 602 025 0A0

Auxiliary Handle

1 602 025 0A0

29.00 RM*

Availability 1

Price group: 23

29.00 RM*

*Prices shown are net prices excluding VAT

Pos. 650/2

Pos. 650/2 | Quick Acting Flange

1 600 A01 6DN

Quick Acting Flange

1 600 A01 6DN

30.00 RM*

Availability 1

Price group: 26

30.00 RM*

*Prices shown are net prices excluding VAT

Pos. 650/5/2

Pos. 650/5/2 | O-Ring 20,35X1,78 MM

1 600 210 055

O-Ring 20,35X1,78 MM

1 600 210 055

2.00 RM*

Availability 1

Price group: 10

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 650/5

Pos. 650/5 | Clamping Flange Ø22,3XØ42 MM

2 605 703 014

Clamping Flange Ø22,3XØ42 MM

2 605 703 014

10.00 RM*

Availability 1

Price group: 20

10.00 RM*

*Prices shown are net prices excluding VAT

Pos. 651

Pos. 651 | Protective Cover

1 600 A02 5XR

Protective Cover

1 600 A02 5XR

23.00 RM*

Availability 1

Price group: 22

23.00 RM*

*Prices shown are net prices excluding VAT

Pos. 808

Pos. 808 | Nameplate

1 601 11A 9C0

Nameplate

1 601 11A 9C0

Availability 1

Price group: -

Pos. 821

Pos. 821 | Gear Housing

1 607 000 D81

Gear Housing

1 607 000 D81

35.00 RM*

Availability 1

Price group: 28

35.00 RM*

*Prices shown are net prices excluding VAT

Pos. 828

Pos. 828 | Bearing Flange

1 607 000 D83

Bearing Flange

1 607 000 D83

79.00 RM*

Availability 1

Price group: 34

79.00 RM*

*Prices shown are net prices excluding VAT

Pos. 828/04

Pos. 828/04 | O-Ring 47,0X1,5 MM

3 600 210 109

O-Ring 47,0X1,5 MM

3 600 210 109

2.00 RM*

Availability 1

Price group: 12

2.00 RM*

*Prices shown are net prices excluding VAT

Pos. 840

Pos. 840 | Push-Button

1 607 000 D7Y

Push-Button

1 607 000 D7Y

5.00 RM*

Availability 1

Price group: 14

5.00 RM*

*Prices shown are net prices excluding VAT

Pos. 851

Pos. 851 | Electronic Module

1 607 000 EB1

Electronic Module

1 607 000 EB1

290.00 RM*

Availability 1

Price group: 46

290.00 RM*

*Prices shown are net prices excluding VAT

Pos. 852

Pos. 852 | Protective Cover

1 600 A02 1MH

Protective Cover

1 600 A02 1MH

6.00 RM*

Availability 1

Price group: 22

6.00 RM*

*Prices shown are net prices excluding VAT

Pos. 884

Pos. 884 | Filter Unit

1 607 000 CA9

Filter Unit

1 607 000 CA9

20.00 RM*

Availability 1

Price group: 23

20.00 RM*

*Prices shown are net prices excluding VAT

Pos. 893

Pos. 893 | Electronics Module

1 607 000 D91

Electronics Module

1 607 000 D91

27.00 RM*

Availability 1

Price group: 24
