Hot Air Gun
GHG 23-66 | 3 601 BA6 301 | /
Lubrication instructions
Product information
Print drawing

To select an item please click on the position number in the illustration or select the item via the part list below the drawing
3 601 BA6 301
Image 1
Motor
-
part
Spare part number: 1 600 A01 N64
Position: 809
Availability: 1
Price group: 31
30.813 TND*
All prices are recommended retail prices including VAT
Heating Element
-
part
Spare part number: 1 600 A01 N6C
Position: 810
Availability: 1
Price group: 39
213.13 TND*
All prices are recommended retail prices including VAT
Power supply cord
-
part
Spare part number: 1 607 000 CW0
Position: 801
Availability: 1
Price group: 31
27.521 TND*
All prices are recommended retail prices including VAT
Screw
-
part
Spare part number: 1 607 000 CW1
Position: 807
Availability: 1
Price group: 10
0.312 TND*
All prices are recommended retail prices including VAT
Printed Circuit Board
-
part
Spare part number: 1 607 000 D0W
Position: 806
Availability: 1
Price group: 42
433.928 TND*
All prices are recommended retail prices including VAT
Housing
-
part
Spare part number: 1 607 000 D0Y
Position: 804
Availability: 1
Price group: 33
35.22 TND*
All prices are recommended retail prices including VAT
Housing
-
part
Spare part number: 1 607 000 D0Y
Position: 804
Availability: 1
Price group: 33
35.22 TND*
All prices are recommended retail prices including VAT
Motor
-
Spare part number: 1 607 000 D1V
Position: 805
Availability: 1
Price group: 41
251.267 TND*
All prices are recommended retail prices including VAT
Nameplate
-
part
Spare part number: 1 607 000 D4K
Position: 808
Availability: 1
Price group: 13
2.391 TND*
All prices are recommended retail prices including VAT
1
Spare parts in cart

8 Parts found

Sort by
Description
Pos. 801 | Power supply cord
1 607 000 CW0
-
27.521 TND*
*All prices are recommended retail prices including VAT
Pos. 804 | Housing
1 607 000 D0Y
-
35.22 TND*
*All prices are recommended retail prices including VAT
Pos. 805 | Motor
1 607 000 D1V
-
251.267 TND*
*All prices are recommended retail prices including VAT
Pos. 806 | Printed Circuit Board
1 607 000 D0W
-
433.928 TND*
*All prices are recommended retail prices including VAT
Pos. 807 | Screw
1 607 000 CW1
-
0.312 TND*
*All prices are recommended retail prices including VAT
Pos. 808 | Nameplate
1 607 000 D4K
-
2.391 TND*
*All prices are recommended retail prices including VAT
Pos. 809 | Motor
1 600 A01 N64
-
30.813 TND*
*All prices are recommended retail prices including VAT
Pos. 810 | Heating Element
1 600 A01 N6C
-
213.13 TND*
*All prices are recommended retail prices including VAT
* All prices are recommended retail prices including VAT
Turn the device for 90 degrees.
3 601 BA6 301
Image 1
Motor
-
part
Spare part number: 1 600 A01 N64
Position: 809
Availability: 1
Price group: 31
30.813 TND*

All prices are recommended retail prices including VAT
Heating Element
-
part
Spare part number: 1 600 A01 N6C
Position: 810
Availability: 1
Price group: 39
213.13 TND*

All prices are recommended retail prices including VAT
Power supply cord
-
part
Spare part number: 1 607 000 CW0
Position: 801
Availability: 1
Price group: 31
27.521 TND*

All prices are recommended retail prices including VAT
Screw
-
part
Spare part number: 1 607 000 CW1
Position: 807
Availability: 1
Price group: 10
0.312 TND*

All prices are recommended retail prices including VAT
Printed Circuit Board
-
part
Spare part number: 1 607 000 D0W
Position: 806
Availability: 1
Price group: 42
433.928 TND*

All prices are recommended retail prices including VAT
Housing
-
part
Spare part number: 1 607 000 D0Y
Position: 804
Availability: 1
Price group: 33
35.22 TND*

All prices are recommended retail prices including VAT
Housing
-
part
Spare part number: 1 607 000 D0Y
Position: 804
Availability: 1
Price group: 33
35.22 TND*

All prices are recommended retail prices including VAT
Motor
-
Spare part number: 1 607 000 D1V
Position: 805
Availability: 1
Price group: 41
251.267 TND*

All prices are recommended retail prices including VAT
Nameplate
-
part
Spare part number: 1 607 000 D4K
Position: 808
Availability: 1
Price group: 13
2.391 TND*

All prices are recommended retail prices including VAT
1
Warning
A selection of part numbers is available. Please click the respective button in the spare part list
Warning
To select this item click the checkbox. Note: This position number does not appear on the illustration
Warning
No spare part listed
