Cordless Percus Screwdriv
GSB 120-LI | 3 601 JG8 180 | 12 V / 026 - AS
Lubrication instructions
Product information
Print drawing

To select an item please click on the position number in the illustration or select the item via the part list below the drawing
3 601 JG8 180
Image 1
Gear Box
-
part
Spare part number: 1 600 A01 2MP
Position: 45
Availability: 1
Price group: 32
60.501 TND*
All prices are recommended retail prices including VAT
Changeover Lever
-
part
Spare part number: 1 600 A01 6SU
Position: 5
Availability: 1
Price group: 10
0.312 TND*
All prices are recommended retail prices including VAT
Nameplate
-
Spare part number: 1 601 11A 6LJ
Position: 808
Availability: 1
Price group: 13
0.422 TND*
All prices are recommended retail prices including VAT
Manufacturer's nameplate
-
Spare part number: 1 601 11C 2WB
Position: 9
Availability: 1
Price group: 13
0.312 TND*
All prices are recommended retail prices including VAT
Housing
-
part
Spare part number: 1 605 806 5M0
Position: 1
Availability: 1
Price group: 21
4.917 TND*
All prices are recommended retail prices including VAT
Housing
-
part
Spare part number: 1 605 806 5M0
Position: 1
Availability: 1
Price group: 21
4.917 TND*
All prices are recommended retail prices including VAT
Motor Spare Parts Set
-
part
Spare part number: 1 607 000 D7K
Position: 802
Availability: 1
Price group: 29
48.40 TND*
All prices are recommended retail prices including VAT
Ferrite
-
Spare part number: 1 607 502 694
Position: 4/1
Availability: 1
Price group: 11
0.634 TND*
All prices are recommended retail prices including VAT
-

Please click for futher details

-

Please click for futher details

Countersunk-Head Screw M6X23 LEFTHAND THREADS
-
part
Spare part number: 2 603 421 229
Position: 107
Availability: 1
Price group: 11
2.507 TND*
All prices are recommended retail prices including VAT
Switch Assembly
-
part
Spare part number: 2 607 202 520
Position: 4
Availability: 1
Price group: 32
84.701 TND*
All prices are recommended retail prices including VAT
-

Please click for futher details

-

Please click for futher details

-

Please click for futher details

-

Please click for futher details

Clip
-
part
Spare part number: 2 609 110 838
Position: 70
Availability: 1
Price group: 10
0.541 TND*
All prices are recommended retail prices including VAT
Keyless Chuck
-
part
Spare part number: 2 609 111 312
Position: 25
Availability: 1
Price group: 34
37.266 TND*
All prices are recommended retail prices including VAT
Screw
-
part
Spare part number: 2 609 111 496
Position: 101
Availability: 7
Price group: 10
1.577 TND*
All prices are recommended retail prices including VAT
Switchover Unit
-
part
Spare part number: 2 609 199 279
Position: 32
Availability: 1
Price group: 10
11.01 TND*
All prices are recommended retail prices including VAT
1
Spare parts in cart

19 Parts found

Sort by
Description
Pos. 1 | Housing
1 605 806 5M0
-
4.917 TND*
*All prices are recommended retail prices including VAT
Pos. 4 | Switch Assembly
2 607 202 520
-
84.701 TND*
*All prices are recommended retail prices including VAT
Pos. 4/1 | Ferrite
1 607 502 694
-
0.634 TND*
*All prices are recommended retail prices including VAT
Pos. 5 | Changeover Lever
1 600 A01 6SU
-
0.312 TND*
*All prices are recommended retail prices including VAT
Pos. 9 | Manufacturer's nameplate
1 601 11C 2WB
-
0.312 TND*
*All prices are recommended retail prices including VAT
Pos. 25 | Keyless Chuck
2 609 111 312
-
37.266 TND*
*All prices are recommended retail prices including VAT
Pos. 32 | Switchover Unit
2 609 199 279
-
11.01 TND*
*All prices are recommended retail prices including VAT
Pos. 45 | Gear Box
1 600 A01 2MP
-
60.501 TND*
*All prices are recommended retail prices including VAT
Pos. 70 | Clip
2 609 110 838
-
0.541 TND*
*All prices are recommended retail prices including VAT
Pos. 91 | Battery Pack GBA 12V 2.0AH LI SCM
1 607 A35 0C5
-
60.003 TND*
*All prices are recommended retail prices including VAT
Pos. 91 | Battery Pack GBA 10.8V 2.0AH LI SCM
1 607 A35 0C9
-
44.093 TND*
*All prices are recommended retail prices including VAT
Pos. 101 | Screw
2 609 111 496
-
1.577 TND*
*All prices are recommended retail prices including VAT
Pos. 107 | Countersunk-Head Screw M6X23 LEFTHAND THREADS
2 603 421 229
-
2.507 TND*
*All prices are recommended retail prices including VAT
Pos. 653 | Fast Charger
2 607 226 187
-
141.136 TND*
*All prices are recommended retail prices including VAT
Pos. 653 | Fast Charger
2 607 226 189
-
35.613 TND*
*All prices are recommended retail prices including VAT
Pos. 653 | Fast Charger GAL 12V-20 MEX 115V / 3.6V – 12V / 2A
2 607 226 195
-
35.578 TND*
*All prices are recommended retail prices including VAT
Pos. 653 | Fast Charger IND GAL 12V-20
2 607 226 541
-
-
Pos. 802 | Motor Spare Parts Set
1 607 000 D7K
-
48.40 TND*
*All prices are recommended retail prices including VAT
Pos. 808 | Nameplate
1 601 11A 6LJ
-
0.422 TND*
*All prices are recommended retail prices including VAT
* All prices are recommended retail prices including VAT
Turn the device for 90 degrees.
3 601 JG8 180
Image 1
Gear Box
-
part
Spare part number: 1 600 A01 2MP
Position: 45
Availability: 1
Price group: 32
60.501 TND*

All prices are recommended retail prices including VAT
Changeover Lever
-
part
Spare part number: 1 600 A01 6SU
Position: 5
Availability: 1
Price group: 10
0.312 TND*

All prices are recommended retail prices including VAT
Nameplate
-
Spare part number: 1 601 11A 6LJ
Position: 808
Availability: 1
Price group: 13
0.422 TND*

All prices are recommended retail prices including VAT
Manufacturer's nameplate
-
Spare part number: 1 601 11C 2WB
Position: 9
Availability: 1
Price group: 13
0.312 TND*

All prices are recommended retail prices including VAT
Housing
-
part
Spare part number: 1 605 806 5M0
Position: 1
Availability: 1
Price group: 21
4.917 TND*

All prices are recommended retail prices including VAT
Housing
-
part
Spare part number: 1 605 806 5M0
Position: 1
Availability: 1
Price group: 21
4.917 TND*

All prices are recommended retail prices including VAT
Motor Spare Parts Set
-
part
Spare part number: 1 607 000 D7K
Position: 802
Availability: 1
Price group: 29
48.40 TND*

All prices are recommended retail prices including VAT
Ferrite
-
Spare part number: 1 607 502 694
Position: 4/1
Availability: 1
Price group: 11
0.634 TND*

All prices are recommended retail prices including VAT
-

Please click for futher details

Countersunk-Head Screw M6X23 LEFTHAND THREADS
-
part
Spare part number: 2 603 421 229
Position: 107
Availability: 1
Price group: 11
2.507 TND*

All prices are recommended retail prices including VAT
Switch Assembly
-
part
Spare part number: 2 607 202 520
Position: 4
Availability: 1
Price group: 32
84.701 TND*

All prices are recommended retail prices including VAT
-

Please click for futher details

Clip
-
part
Spare part number: 2 609 110 838
Position: 70
Availability: 1
Price group: 10
0.541 TND*

All prices are recommended retail prices including VAT
Keyless Chuck
-
part
Spare part number: 2 609 111 312
Position: 25
Availability: 1
Price group: 34
37.266 TND*

All prices are recommended retail prices including VAT
Screw
-
part
Spare part number: 2 609 111 496
Position: 101
Availability: 7
Price group: 10
1.577 TND*

All prices are recommended retail prices including VAT
Switchover Unit
-
part
Spare part number: 2 609 199 279
Position: 32
Availability: 1
Price group: 10
11.01 TND*

All prices are recommended retail prices including VAT
1
Warning
A selection of part numbers is available. Please click the respective button in the spare part list
Warning
To select this item click the checkbox. Note: This position number does not appear on the illustration
Warning
No spare part listed
