Drill
GBM 400 | 3 601 AC1 0K0 | 230 V / 026 - AS
Lubrication instructions
Product information
Print drawing

To select an item please click on the position number in the illustration or select the item via the part list below the drawing
3 601 AC1 0K0
Image 1
Motor Housing
-
Spare part number: 1 619 PB8 883
Position: 1
Availability: 1
Price group: -
-
Motor Housing
-
Spare part number: 1 619 PB8 883
Position: 1
Availability: 1
Price group: -
-
Field
-
Spare part number: 1 619 PB8 884
Position: 2
Availability: 1
Price group: -
-
Switch
-
Spare part number: 1 619 PB8 886
Position: 4
Availability: 1
Price group: -
-
Power supply cord
-
Spare part number: 1 619 PB8 888
Position: 5
Availability: 1
Price group: -
-
Nameplate
-
Spare part number: 1 619 PB8 892
Position: 808
Availability: 1
Price group: -
-
Ball Bearing
-
Spare part number: 1 619 PB8 897
Position: 13
Availability: 1
Price group: -
-
Ball Bearing
-
Spare part number: 1 619 PB8 898
Position: 14
Availability: 1
Price group: -
-
Brush Holder
-
Spare part number: 1 619 PB8 899
Position: 16
Availability: 2
Price group: -
-
Brush Holder
-
Spare part number: 1 619 PB8 899
Position: 16
Availability: 2
Price group: -
-
Suppression Capacitor
-
Spare part number: 1 619 PB8 901
Position: 24
Availability: 1
Price group: -
-
Felt Seal
-
Spare part number: 1 619 PB8 903
Position: 26
Availability: 1
Price group: -
-
Tapping Screw
-
Spare part number: 1 619 PB8 904
Position: 28
Availability: 7
Price group: -
-
Reversing Switch
-
Spare part number: 1 619 PB8 905
Position: 33
Availability: 1
Price group: -
-
Ball Bearing
-
Spare part number: 1 619 PB8 909
Position: 45
Availability: 1
Price group: -
-
Keyless Chuck
-
Spare part number: 1 619 PB8 910
Position: 46
Availability: 1
Price group: -
-
Armature set
-
Spare part number: 1 619 PB8 917
Position: 803
Availability: 1
Price group: -
-
Drilling Spindle
-
Spare part number: 1 619 PB8 918
Position: 841
Availability: 1
Price group: -
-
Carbon-Brush Set
-
Spare part number: 1 619 PB8 919
Position: 810
Availability: 1
Price group: -
-
Grommet
-
Spare part number: 1 619 PB9 031
Position: 6
Availability: 1
Price group: -
-
1
My spare part list

18 Parts found

Sort by
Description
Pos. 1 | Motor Housing
1 619 PB8 883
-
-
Pos. 2 | Field
1 619 PB8 884
-
-
Pos. 4 | Switch
1 619 PB8 886
-
-
Pos. 5 | Power supply cord
1 619 PB8 888
-
-
Pos. 6 | Grommet
1 619 PB9 031
-
-
Pos. 13 | Ball Bearing
1 619 PB8 897
-
-
Pos. 14 | Ball Bearing
1 619 PB8 898
-
-
Pos. 16 | Brush Holder
1 619 PB8 899
-
-
Pos. 24 | Suppression Capacitor
1 619 PB8 901
-
-
Pos. 26 | Felt Seal
1 619 PB8 903
-
-
Pos. 28 | Tapping Screw
1 619 PB8 904
-
-
Pos. 33 | Reversing Switch
1 619 PB8 905
-
-
Pos. 45 | Ball Bearing
1 619 PB8 909
-
-
Pos. 46 | Keyless Chuck
1 619 PB8 910
-
-
Pos. 803 | Armature set
1 619 PB8 917
-
-
Pos. 808 | Nameplate
1 619 PB8 892
-
-
Pos. 810 | Carbon-Brush Set
1 619 PB8 919
-
-
Pos. 841 | Drilling Spindle
1 619 PB8 918
-
-
* Recommended retail price excluding GST
